Non-standard Centrifugal Constant Acceleration Testing Machine

Non-standard Centrifugal Constant Acceleration Testing Machine

Non-standard Centrifugal Constant Acceleration Testing Machine Components Steady-state Acceleration Environment Test Centrifuge Steady state acceleration centrifugal testing machine is used to determine the force (except gravity) of electronic components, small equipment and other electrical and electronic products subjected to dynamic overload environment. The structural compatibility and performance are good, as well as the evaluation of the structural integrity of some components, and verify that these components under the expected use of the environment under the combined acceleration stress is normal and the bearing capacity of the structure.

описание

Product Characteristics

Military products do simulation of dynamic centrifugal movement, centrifugal movement of dual environmental force and center high-speed rotating movement,a test means to examine the load resistance of electronic components, small components and other electrical and electronic products and test the load resistance performance index test equipment. It is mainly used for routine dynamic structural integrity and adaptability test of components, small parts and small machine on aircraft. Equipment features: High acceleration rate; Computer centralized control and measurement; Full digital network closed-loop remote control, high control precision; Complete security protection functions.

Product Characteristics

Model number	HJ-1	HJ-2	HJ-3	HJ-4	HJ-5
parameter	Double ambient centrifugal constant acceleration tester	High speed spin testing machine	Centrifugal dynamic overload testing machine	Spin impact composite testing machine	Centrifugal vibration composite testing machine
Simplex load (KG)	5	5	50	3	1000
Maximum acceleration (G)	150	/	20	Impact 10000G-IMS	50G
Loading rate (G/S)	Customized according to user requirements	/	10	/	Standard electromagnetic shaking table specifications
Mounting radius (MM)	Customized according touser requirements	/	1500	/	Customized according to user requirements
Spin speed (R/MIN)	0-3000	0-100000	/	0-10000	/
Collecting ring device	Optional according to user requirements
Control mode	Full closed loop digital network (remote) automatic control +manual control
Power supply	AC 380V± 10% 50HZ
Working environment	Temperature 0-40℃ humidity < 80% (no condensation)
Meet the criteria	GB/T 2423. GJB 150A, GJB1027,GJB360B

Non-standard Centrifugal Constant Acceleration Testing Machine
