Pulse testing machine

Pulse testing machine is mainly used for pressure fatigue test of products. Impulse test of automobile hose steering pipe, brake pipe, air conditioning pipe, fuel pipe, cooling pipe, cooling hose, heating hose, air filter hose, worm gear booster system hose, engineering hydraulic hose, aviation hose and manifold, other hard pipes or joints, heat exchanger, air conditioner, filter, etc.

описание

Technical parameter：

Test pressure	0-70MPA (pressure optional)
Pressure control accuracy	The upper limit of the test pressure value is +2%, the lower limit is -1%
Temperature control accuracy	The mean difference is +1C and the maximum deviation is +2°c
Pressure resolution	0.01 BAR
Pulse frequency	5-30 reps per minute
Test medium	Water or hydraulic fluid
Pulse pressure waveform	Basic square wave (or trapezoidal wave), pulse width adjustment can be in accordance with your company's requirements
Test medium temperature	Room temperature ~130° (according to customer requirements)
Number of tests	For more than 500,000 times (one consecutive time), the continuous working time can be more than 30 days, the sealing performance test, no leakage or deformation
Mode of operation	Computer control
Sample mounting mode	Manual or automatic clamping
Structural composition	Power system, circulation system, pressure control system, workpiece mounting device, computer control
