Features of Zero drop tester
The zero drop tester is mainly used to evaluate the impact of the packaged parts on the impact of drop during the actual transportation, loading and unloading process, and to evaluate the impact resistance strength of the packaged parts during the transportation process and the rationality of the packaging design. The zero drop tester is mainly used for the drop test of larger packages.
Parameters of Zero drop tester
| Maximum weight of test piece | 160(kg) |
| Test space | Calculated by customer product |
| Test height | 0~1000mm can be set freely |
| Test aspects | edge, angle, face |
| Working power | 380V/50HZ |
| Drive mode | Motor driven |
| Protective device | There are induction protection devices on the top and bottom |
| Impact plate material | 45# steel, solid steel plate |
| Height display | LED digital display, and can set the altitude stop function |
