It is suitable for impact test on samples or products of non-metallic materials such as plastic pipes, glass, ceramics, etc., is a test instrument used to evaluate the impact resistance of materials, touch screen display of lifting height, intuitive and accurate, pneumatic to prevent secondary impact. It is suitable for external impact resistance of various pipes (PVC-U water supply pipes, sewage pipes, low pressure water supply pipes, low pressure water delivery pipes, core foam pipes, double-wall corrugated pipes, PE water supply pipes, MPP power pipes) and plates. The determination is also applicable to rigid plastic sheets.
Parameters of Packaging material buffer strength tester
| Slide drop height | 1200mm |
| Drop weight | 50kgf |
| Light weight | 2kgf |
| Weight of heavy platform | 7kgf |
| Small weight gain | 1kgf |
| Weight quality and quantity | 0.6kg*1, 1kg*1, 2kg*2, 5kg*3, 10kg*1, 20kg*1 |
| Maximum impact energy | 300 J |
| Hammer mass | 0.5Kg～6.3Kg |
| Hammer head curvature radius | One each for d25R50 and d90R50 |
| impact height | 2000mm and below |
| Impact height error | ±2mm |
| Specimen Specifications | Φ16mm～Φ800mm |
| Power supply | 220V, 50Hz |
| Dimensions | 800×800×4100mm |
| Total Weight | 380kg |
