The keyboard key life tester can perform experimental life test on mobile phone keys, MP3, computer keyboard, electronic dictionary, remote control, rubber keys and other products, and is suitable for testing key switches, tact switches, membrane switches and other keys for life test.
Features of Computer keyboard key life testing machine
With adjustable speed, the number of times can be set arbitrarily, and several products can be tested at the same time (each product can be tested at multiple points). In addition, each button can be set to different pressures and different heights. At the same time, each test head is used for separate control, special fixture design, and humanized operation, which can meet the different test needs of customers.
Parameters of Computer keyboard key life testing machine
| Action stroke | 10mm (fixed) |
| Working height adjustment range | 100mm |
| Fixture holding capacity | 400*300mm |
| Probe installation range | 350*250mm |
| Number of trials | 999999*10次 |
| Test speed | 60-300Rpm |
| Probe height adjustment | 15mm |
| Number of probes | 15 (expandable to 120) |
| Minimum distance between two probes | X direction 10mm, Y direction 20mm |
| Physical dimension | 520*420*980mm |
| Weight | 110kg |
| Voltage | AC 220V |
