Bicycle Disc Brake Fatigue Testing Machine

This testing machine is designed according to the test standard of bicycle drop braking fatigue resistance. It uses servo cylinder to exert force. After the bicycle frame is installed on the fixture of this testing machine and fixed, it is subjected to fatigue force with a certain frequency, load and number of tests. After the end, it is judged by checking the degree of damage to the sample.


Parameters of Bicycle Disc Brake Fatigue Testing Machine

Test force value accuracy±5%
Maximum working amplitude (mm)±100
Motion detectorLVDT accuracy ±0.01mm
Power sourceAir pressure servo control system
Frequency Range1HZ-8HZ adjustable
Software interfaceLizhi Precision Control System
Dimensions (W*D*H)Host 2500*600*1500(cm)
Weight (approx.)160KG
Power supplyAC220V, 15A
Air source requirementsNeed to prepare 7Kg/cm2 dry air source
