Product parameter table
Product number | HJ-400×200 | HJ-400×400 | HJ-400×600 | HJ-400×1200 |
Nominal clamping force (MN) | 0.25 | 0.5 | 0.8 | 1.6 |
Hot plate specification(mm) | 400×200 | 400×400 | 400×600 | 400×1200 |
Hot plate unit area pressure Mpa | 2.5 | 2.5 | 2.5 | 2.5 |
Main motor power kw | 2.2 | 2.2 | 2.2 | 3 |
Vulcanized belt inner circumference kw | 960 - 3500 | 1680 - 3600 | 1680 - 3700 | 5000 - 17000 |
Dimensions (L×W×H)mm | 3200 x 1050 x1730 | 3200x1050x1730 | 3200x1050x1730 | 3200x1050x1730 |
Product weightkg | 4000 | 5000 | 5000 | 8000 |
