Castor durability tester, suitable for testing all kinds of castor durability, wear resistance; Different casters pressure different weights; The weight level can be customized. Mainly for industrial casters, hotel, supermarket wheelbarrow wheel, luggage casters, mechanical equipment, medical equipment, kitchenware, office chairs and other 25mm-250mm casters for "dynamic test", "long-distance walking test", "static load test", digital display, can control speed, time, display force value.
Parameters of Chair caster durability testing machine
| Loading weight | 20kg, 20KG, 10KG, 5KG |
| Machine weight | 2T |
| Test speed | 0~17km/h |
| Number of tests | 1~ 999,999 times (number of blocks) |
| Test time | 1~999999min |
| Test mileage | 1~999999m |
| Direction of operation | Positive inversion is optional |
| Obstacle height | 2mm/4, 3mm/4 |
| Display mode | Touch screen display |
| Control mode | PLC control |
| Power source | AC/220V, 5A, 50HZ |
| Atmospheric pressure | ≥6kg/cm2 |
| Overall power | 4.5 KW |
| Machine size | 1700*1200*3100mm (W*D*H) |
